ELECTRICAL RESISTANCE PER SECTION - 5.000 KILOHMS SINGLE SECTION RESISTANCE TOLERANCE PER SECTION IN PERCENT - -5.0 TO 5.0 SINGLE SECTION STANDARD TAPER CURVE PER SECTION - A SINGLE SECTION MAXIMUM STOP TORQUE - 15.00 INCH-OUNCES MAXIMUM STARTING TORQUE - 5.00 INCH-OUNCES MAXIMUM RUNNING TORQUE - 5.00 INCH-OUNCES TEMP COEFFICIENT OF RESISTANCE PER SECTION IN PPM PER DEG CELSIUS - -50.0 TO 50.0 SINGLE SECTION POWER DISSIPATION RATING PER SECTION IN WATTS - 1.5 FREE AIR SINGLE SECTION AMBIENT TEMP IN DEG CELSIUS PER SECTION AT FULL RATED POWER - 70.0 SINGLE SECTION AMBIENT TEMP IN DEG CELSIUS PER SECTION AT ZERO PERCENT RATED POWER - 175.0 SINGLE SECTION BODY DIAMETER - 0.500 INCHES NOMINAL BODY LENGTH - 0.180 INCHES NOMINAL ACTUATOR TYPE - FLUSH DRIVE WITH SLOT-HOLE ROTARY ACTUATOR TRAVEL IN ANGULAR DEG - 320.0 NOMINAL ACTUATOR TRAVEL CONTROL FEATURE - STOPS EFFECTIVE ELECTRICAL ROTATION IN DEG ANGULAR ROTATION - 300.0 NOMINAL MOUNTING METHOD - PRINTED CIRCUIT TERMINAL TYPE AND QUANTITY - 3 PIN CENTER TO CENTER DISTANCE BETWEEN TERMINALS - 0.200 INCHES NOMINAL CENTER TO CENTER DISTANCE BETWEEN CENTER TERMINAL AND OUTSIDE TERMINAL - 0.100 INCHES NOMINAL TERMINAL LENGTH - 0.188 INCHES NOMINAL RELIABILITY INDICATOR - NOT ESTABLISHED (all content is the responsibility of the poster) |
