Only FIVE lots of NINETEEN remaining! We just bought out a long time Phoenix surplus electronics distributor. All of these parts are absolutely "as new", most are aerospace quality, and most are leading traditional American brands. The bulk of the items are unused production overstock. Offered items are not ROHS compatible or compliant. Offered here are lots of nineteen premium grade DC power jacks that include TWO disconnecting switches. The second switch is highly useful for Lithium battery charging or switching in a current limiting resistor. We are fairly sure these are Kobiconn part number 163-4314. These are slightly larger than typical power jacks owing to the second switching contact. There are five thru-hole pc mounting pins. These can also be direct soldered. Side slots allow hardware free mounting in a compatible case. Apparently intended for the most common 5.5 mm outside diameter, 2.5 mm inside diameter dc power plugs widely used on wall warts. Noryl black plastic with silver plated brass contacts. Inner pin is 7.5 mm long. Power jack approximates a half inch cube. Contacts rated 0.5 amps. Guaranteed usable. Power jacks received in "as new" and apparently unused condition, some in individual poly bags and some as loose distributor stock. Switches may include minor storage cosmetics. Current production. You can click here to reach the Full specs, switch schematics, and dimensional drawings. (all content is the responsibility of the poster) |
