* Rated Input Voltage and Frequency: 3-phase, 380 to 460 V, 50/60 Hz * Maximum Output Voltage: 3-phase, 380 to 460 V (proportional to input voltage) * Maximum Applicable Motor Output: 5HP (3.7kW) * Rated Output Current: 8.6 Amps * Maximum Output Frequency: 400Hz (programmable) * Control Method: Sine wave Pulse Width Modulation (V/f control) * Frequency Control Range: .1 to 400 Hz * Overload Capacity: 150% rated output current for one minute * Frequency Reference Signal: 0-10 VDC, 4 to 20 mA, 0 to 20 mA frequency setting volume (selectable) * Accel/Decel TIme: 0.1 to 999 seconds (accel./decel. time are independently programmed) * Motor Overload Protection: Electronic thermal overload relay * Multi-function Input: Four of the following input signals are selectable: Reverse run (3-wire sequence), fault reset, external fault (NO/NC contact input), multi-step speed operation, Jog command, accel/decel time select, external baseblock (NO/NC contact input), speed search command, accel/decel hold command, LOCAL/REMOTE selection, communication/control circuit terminal selection, emergency stop fault, emergency stop alarm. * Multi-function Output: Following output signals are selectable (1 NO/NC contact output): Fault, running, zero speed, at frequency, frequency detection (output frequency< or > set value), during overtorque detection, minor error, during baseblock, operation mode, inerter run ready, during fault retry, during under-voltage, during speed search, data output through communication. * All configuration perimeters are accessible through the integrated operator console. * Easy to install, set up, maintain and program * Space-saving design ideal for new or retrofit panels * Integrated, face-mounted speed potentiometer for quick start up after power is applied * Quick start LEDs for easy programming * Communication option include RS0232C/485 * Multi-step speed control for up to nine steps, UP/DOWN operation, and jog operation * Ideal for simple, low horsepower speed control applications * Excellent starting torque of 150% at 3Hz * Virtually immune to overload * Consistent perfolmance despite changing conditions * Full-range automatic torque boost * Supports analog inputs of 0 to 10 V, 4 to 20 mA, or 0 to 20 mA * Supports an analog monitor output and a digital output * Accepts both PNP and NPN inputs * A high-speed current limiting function minimizes over-current trips (above 250% of rated current) * Quick restarts after momentary power loss * Stall prevention and fault retry funtions * UL recognized electronic thermal overload * Inrush current suppression and ground fault protection (all content is the responsibility of the poster) |
