RFMD RF IC 433 868 915MHZ FM/FSK/ASK/OOK TRANSCEIVER The RF2905 is a monolithic integrated circuit intended for use as a low cost FM transceiver. The device is provided in 7mmx7mm, 48-lead plastic LQFP packaging and is designed to provide a fully functional FM transceiver. The chip is intended for linear (AM, FM) or digital (ASK, FSK,OOK) applications in the North American 915MHz ISM band and European 433MHz and 868MHz ISM bands. The integrated VCO, dual modulus/dual divide (128/129 or 64/65) prescaler, and reference oscillator require only the addition of an external crystal to provide a complete phase-locked oscillator. * Fully Monolithic Integrated Transceiver * 2.7V to 5.0V Supply Voltage * Narrow Band and Wide Band FM/FSK * 300MHz to 1000MHz Frequency Range * 10dB Cascaded Noise Figure * 10mW Output Power at 433MHz * You can download a datasheet. Click here * S&H will be US $ 1.5 from 2nd item. * Air mail will take 7~ 15days. If you are not satisfied with your item, you may return it unused and in its original condition for a refund. * Refund(If accepted) must be requested 7 days upon receipt of goods * Exchange only if the item is not working properly It is the price per IC. Thanks Certain images and/or photos used in this template are the copyrighted property of JupiterImages and are being used with permission under license. (all content is the responsibility of the poster) |
