Input Voltage:Minimum:17,Nominal:48 Max:60=VDC unit. Input Current No Load:Nominal-42,mA DC. Input Current Full load:Nominal-510,mA DC. Refected Ripple Current:Nominal 50,mA P-P. Output Voltage:Minimun:5.544/12.375/4.9,Nominal:+5.6/+12.5/-5.0,Max:5.656/12.625/5.1,VDC. Output Current:Minimum:1000/75/10,Max:3000/200/75,mA DC. Current Limit:Short Circuit Protection,mA DC. Line Regulation:Max:28/63/25.mv-DC Load Regulation:Max:56/125/50,mV DC Temperture Coefficient: mV/*C. Output Ripple BW=20 mhz,:Max 75.mV P-P Switching Frequency:Minimum:210,Nominal:250,Max: 290, KHz OVP Traip Point:Nominal:6.8/15/6.8,VDC. Isolation Input to Output:Minimum:500,VDC. Isolation Input to case:Minimum:500,VDC. Isolation Output to Case:Minimum:500,VDC. Isolation Resistance:Minimum:500,M _[ ]_. Storage Temp:Minimum: -55,Max: 100,*C. Operating Temp.:Minimum: -25,Max:85, *C case. Thermal Shock-Rate of Change:*C/Min. Length: Nominal:3, Max 3.1 inches. Width:Nominal: 3, Max 3.1 inches. Height:Nominal:0.4, Max 0.45 inches. (all content is the responsibility of the poster) |
j-vaughan@oklahomaselltoday.com (Julie Vaughan) for more information. All emails will be forwarded to the poster's actual email address.
