2 Channel 200 Mhz 5GS/s Equiv Sampling High Performing - High Bandwidth USB Interface - Suitable For Professional Engineering Don't be fooled by the low price! This is not a toy! NEW - NOT USED OR REFURBISHED! One year replacement warranty against manufacturing defects A Digital Storage Oscilloscope is an indispensable instrument for research, development and production. However, a stand-alone high bandwidth digital oscilloscope is expensive and an inexpensive low bandwidth PC based oscilloscope is not suitable for professional engineering. 200DS is designed with full knowledge of high speed digital signal processing and software development. The result is an inexpensive PC based oscilloscope with the power of middle/high end stand-alone digital oscilloscopes. Combined with a PC/Notebook PC with USB interface, the 200DSO becomes a powerful diagnostic & engineering tool at a fraction of the cost for an equivalent stand alone unit. With SoftDSP's expertise in high speed analog/digital signal processing and computer applications, 200DSO combines all the traditional benefits of a Digital Storage Oscilloscope.From 200MHz bandwidth, 5 GS/s equivalent sampling to advanced triggering options (Logic, Pulse and Delay). If features characteristics such as higher true color (32bits) waveform grading, and automated data transfer to Microsoft Excel and Word. Unlike conventional card or parallel port connections, there is no need to open up your PC nor is there a need to carry bulky external power adapters for portability. Using 12Mbps, Universal Serial Bus (USB)-powered interface, 200DSO, about the size of your palm, is a true plug-and-play solution. Simply plug it in to USB port and it is ready to work any time, anywhere. Take 200DSO wherever you go The USB interface offers several advantages over conventional serial and parallel connections, including higher bandwidth (up to 12Mbps), no tedious configuration processes, reliable friction-fit connection and the ability to provide power to peripheral devices. Simply plug the USB cable into your PC and 200DSO, execute the software and you are ready to test wherever you are. Use 200DSO on the field, bring it back to your office and hot plug it to a desktop computer without additional PC hardware. USB’s portability provides increased versatility, allowing the instruments to be easily moved or safely stored away when not in use. Wide bandwidth, blazing sampling rate Proprietary variable gain amplification architecture boosts the 200DSO's analog bandwidth up to 200MHz, with only 2.5 Watts supplied from USB. According to the Nyquist Sampling Theorem, one of the most important rules of sampling, the highest frequency which can be accurately represented, is one-half of the sampling rates. In practice, however, given errors in digital signal processing, the range of frequencies needed to faithfully record an analog signal is one-fifth the sampling rate. So reconstructing a 200MHz signal demands more than 1GS/s sampling rate. Overcoming these physical restrictions, our 200 ps-resolution Time-to-Digital Converter (TDC) technology implements on the 5GS/s equivalent sampling rate, using a real time rate of 100MS/s. Powerful software provided - SoftScope Every purchase of a 200DSO includes SoftScope. SoftScope is a compact, easy-to-use analysis tool that will improve productivity and measurement quality. Affordable and powerful, its ability to display, store and analyze complex signals in real time, combined with its advanced triggering and analysis capabilities clearly define it as the oscilloscope’s newer choice of today. 200DSO will provide you with: XY cursor function, 23 measurement functions, Arithmetic function, FFT with windows options (Rectangular, Hanning, Hamming, and Blackman), Persistence/intensity control, Dots line on/off function for versatility in waveform display and much more. SPECIFICATIONS: New Revisions In Red Realtime sampling: 100MS/s using one channel, 50MS/s using two channels Equivalent sampling:5GS/s * Bandwidth: 200MHz(-3dB) Single shot bandwidth: 50MHz (20MHz bandwidth limiting function is available) * Vertical resolution: 9 bits/channel * Gain range: 10mV ~ 10V/div @ x1 probe (10mV, 20mV, 50mV, 100mV, 200mV, 500mV, 1V, 2V, 5V, 10V/div 1,2,5 sequence) 100mV ~ 100V/div @ x10 probe 1V ~ 1000V/div @ x100 probe * Offset level: +/-4 divisions * Coupling: AC, DC, GND(S/W) * Offset increments: 0.02div * Input protection: 42Vpk(DC + peak AC < 10kHz, without external attenuation) * Timebase range: 2ns/div ~ 10s/div (2ns, 4ns, 10ns, 20ns, 40ns, 100ns, 200ns, 400ns, 1us, 2us, 4us, 10us, 20us, 40us, 100us, 200us, 400us, 1ms, 2ms, 4ms, 10ms, 20ms, 40ms, 100ms, 200ms, 400ms, 1s, 2s, 4s, 10s/div 1-2-4 sequence) * Acquisition mode: Equivalent sampling: 2ns/div ~ 4us/div Realtime sampling: 10us/div ~ 400ms/div Roll mode: 1s/div ~ 10s/div Peak Detection * Pre/Post trigger: 0% ~ 1000% * Buffer size: 10K ~ 512K samples * TYPE: Edge trigger: Rising edge, falling edge Pulse trigger: Less than width, more than width(10ns ~ 167ms) Delay trigger: By event(1 ~ 16,777,215), by time(1us ~ 167ms) * Mode Auto, Normal and Single * Settabillity: 0.02 div increments * Trigger level: +/-4 divisions * Measurements: Vp-p, Vmax, Vmin, Vmean, Vrms, Vamp, Vhigh, Vlow, positive overshoot, negative overshoot, cycle mean, cycle rms, period, frequency, positive pluse width, negative pulse width, rise time(10% ~ 90%), fall time(10% ~ 90%), positive duty cycle, negative duty cycle * Cursor: Time/frequency difference, voltage difference Frequency only in FFT mode * Math: Addition, subtraction, multiplication, division * FFT: Rectangular, Hanning, Hamming, Blackman Window * Interface: Universal Serial Bus(USB) * Power: No external power source required. Bus-powered from USB * Calibration Signal Ouput: 3V, 1kHz, Square Wave * Dimensions: 5.1" x 4.4" x 1.5" * Interface: User-friendly Graphic User Interface(GUI) Microsoft Windows standard interface * Display: Graphic engine: Microsoft DirectX Screen size: 500 x 400 Intensity level: 128(Color and monochrome) Persistence control: 100ms ~ 10s Labeling function * File management Image save: BMP, JPG(color/black&white) Data save: DAT OLE(Object Linking and Embedding) automation: Data generation for Microsoft Excel/Word Setting save/load * Print: Print in color/black&white Preview function BEFORE YOU ORDER PLEASE READ BELOW (all content is the responsibility of the poster) |
