ELECTRICAL RESISTANCE PER SECTION - 2.500 KILOHMS SINGLE SECTION RESISTANCE TOLERANCE PER SECTION IN PERCENT - -10.0 TO 10.0 SINGLE SECTION STANDARD TAPER CURVE PER SECTION - A SINGLE SECTION MAXIMUM STOP TORQUE - 240.00 INCH-OUNCES MAXIMUM STARTING TORQUE - 40.00 INCH-OUNCES POWER DISSIPATION RATING PER SECTION IN WATTS - 12.5 FREE AIR SINGLE SECTION AMBIENT TEMP IN DEG CELSIUS PER SECTION AT FULL RATED POWER - 25.0 SINGLE SECTION AMBIENT TEMP IN DEG CELSIUS PER SECTION AT ZERO PERCENT RATED POWER - 340.0 SINGLE SECTION BODY STYLE - 1B CYLINDRICAL BUSHING MOUNTED BODY DIAMETER - 1.880 INCHES MAXIMUM BODY LENGTH - 1.750 INCHES MAXIMUM MOUNTING BUSHING LENGTH - 0.375 INCHES NOMINAL SHAFT STYLE - 3C ROUND, SLOTTED SHAFT DIAMETER - 0.250 INCHES NOMINAL SHAFT LENGTH - 0.875 INCHES NOMINAL ROTARY ACTUATOR TRAVEL IN ANGULAR DEG - 280.0 MINIMUM AND 305.0 MAXIMUM ACTUATOR TRAVEL CONTROL FEATURE - STOPS NONTURN DEVICE LOCATION - AT 12 OCLOCK NONTURN DEVICE RADIUS - 0.500 INCHES NOMINAL MOUNTING METHOD - STANDARD BUSHING SCREW THREAD SERIES DESIGNATOR - UNEF SCREW THREAD DIAMETER - 0.375 INCHES NOMINAL SCREW THREAD QUANTITY PER INCH - 32.0 TERMINAL TYPE AND QUANTITY - 3 TAB W/SCREW RELIABILITY INDICATOR - NOT ESTABLISHED III OVERALL LENGTH - 3.187 INCHES MAXIMUM III OVERALL DIAMETER - 1.880 INCHES MAXIMUM NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE - MILR22-4 DEFINITIVE GOVERNMENT SPEC/STD REFERENCE - RP111SD252KK (all content is the responsibility of the poster) |
