FREE !! Adapter MCS-51 / AVR + PLCC44 / 1 Qty. FREE !! Adapter DIP28 to PLCC32 / 1 Qty. FREE !! Adapter SMD 24Cxx, 93Cxxp / 1 Qty. Adapter DIP332 to PSOP44 Socket (Am29F/28F) Adapter DIP32 to MCS-51+AVR+PLCC44 Adapter DIP28,32 to PLCC32 (3 in 1) Adapter DIP32 to 27Cxxxx ( EPROM 16bit ) Advanced Willem EPROM Programmer PCB4.5C© ( NEWEST!!! ) * This is the newest Willem EPROM Progrmmaer from the original producer/developer of Willem EPROM Programmer version: PCB3b, PCB3.5, PCB4C and PCB4.5C and software versions: 0.98D5 , 0.98D2, 0.97ja, 0.97j, 0.97i+, 0.98i or (0.97i), 0.97h and 0.97g. * This PCB4.5C is new design from the oirginal engineer who developer software 0.98D5 and design PCB3b. It means this PCB fully support software 0.98D5. It doesn't like other saller who just reverse engineering our PCB3b to PCB5 or PCB 5.5 Pro for be equal to PCB4.5C. Because software version 0.98D5 supports only PCB4.5C that the software version 0.98D5 maybe not STABLE whit the PCB reverse engineering. * Updated software version 0.98D5 supports MORE chips (EPROM, EEPROM, FLASH, I2C,PIC, MCS-51,AVR, 93Cxx, ISP) and more. Advanced Willem EPROM Programmer PCB4.5C© * Refreshing , Upgrading, Programming BIOS chips. * Copier, Fax machine, Printer main board maintaining or repairing. * Car memory device code reading, writing. * VCD, DVD, Color TV maintaining or repairing. * Neon Light Controller code writing. * MCU development - programming for MCS-51 series, AVR series and PIC series MCU. * Repairing, reading, writing, programming PC motherboard BIOS Chips. * Upgrade the chip in your cars computer. * Programming MicroChip PIC Micros. * Programming ATMEL AVR Micros. Hardware & Software Features : * The newest Willem EPROM PProgrammer PCB4.5C©. It can program up to 20% - 50% faster than old version of Willem EPROM Programmer * Built-in PLCC32 and PLCC Firmware HUB/LPC on-board - EPROM, EEPROM, Serial (I2C) EEPROM, Microwire EEPROM, Microchip PIC - FLASH Burner (Vpp 12.5V,21V,25V), Serial Peripheral Interface (SPI) - Micro controllers MCS-51, MCS-48 - Test nonvolatile SRAM, static RAM, ATMELand etc. * This Willem EPROM PProgrammer PCB4.5C© only can support the chip 29/39/49LVxxx (Low Voltage 3.3V). * Uses the power supply from the USB Port or AC/DC adaptor power * Note: Higher Vcc voltages (5.6v and 6.2v) will be available when an external AC power supply is used. * able unprotect the AM29F040B flash memory chip. * The back of circuit board is covered by a sheet of perspex and completely protected from a short circuit. * Supports Win9X, Me, XP, NT, 2000 and VISTA operating systems * Updated software version0.98D5. * Add device ID,Menu,Table index :28F002/004/200/400BX-x (TSOP40A,TSOP48 8/16bit, PSOP44) Version 098D5 * Fixed Program Config PIC16F8x, PIC16F62x, PIC16F87x * (Test on PIC16F84, PIC16F84A, PIC16F627/628/628A, PIC16F872/877) * Fixed Timming Programming PIC12C5xx (Run on Windows XP) * Test on PIC12C509JW UV erase), PIC16C505JW (UV erase),PIC12F509 (select device = PIC12C509A) * Add PIC microchip 14bit * PIC12F629/675 , PIC16F630/676 , PIC12F635/683 , PIC16F636/684/688 , PIC16F72/73/74/76/77 , PIC16F737/747/767/777 , PIC16F87/88 , rfPIC12F675x , PIC16F785/PS200 , PIC16F716 * Add microchip 14bit OTP * PIC12C671 , PIC12C672 , PIC12CE673 , PIC12CE674 , PIC16C61/71 , PIC16C62/64/65/73 , PIC16C62A/62B/62C/63/63A/64A/65A/65B/66/67 , PIC16C72/72A/73A/74A/74B/76/77 , PIC16C620/620A/621/621A/622/622A , PIC16CE/623/624/625 , PIC16C710/711/712/716 , PIC16C773/774 , PIC16C745/765/923/924 , PIC16C925/926 , PIC16C554/556/557/558 , PIC16C432/433 , PIC16C717/770/771/781/782 * Add PIC microchip 12bit (FLASH memory) * PIC12F508/509 , PIC10F200/202/204/206 , PIC16F505 , PIC16F54/57 * PIC18F242 , 18F248 , 18F252 , 18F258 , 18F442 , 18F448 , 16F452 , 16F458 PIC18F1220 , 18F2220 , 18F4220 , 18F1320 , 18F2320 , 18F4320 PIC18F6520 , 18F6620 , 18F6720 , 18F8520 , 18F8620 , 18F8720 PIC18F2331 , 18F2431 , 18F4331 , 18F4431 PIC18F6525 , 18F6621 , 18F8525 , 18F8621 PIC18F6585 , 18F6680 , 18F8585 , 18F8680 PIC18F2439 , 18F2539 , 18F4439 , 18F4539 PIC18F6410 , 18F8410 , 18F6490 , 18F8490 * PIC18F2410 , PIC18F2420 , PIC18F2455 PIC18F2510 , PIC18F2515 , PIC18F2520 , PIC18F2525 , PIC18F2550 , PIC18F2585 PIC18F2610 , PIC18F2620 , PIC18F2680 PIC18F4410, PIC18F4420 , PIC18F4455 PIC18F4510 , PIC18F4515 , PIC18F4520 , PIC18F4525 , PIC18F4550 , PIC18F4585 PIC18F4610 , PIC18F4620 , PIC18F4680 * Add Find and edit value OSCCAL (PIC12F629/675 , PIC16F630/676) * Add Edit config at address 0x2008,0x2009 (PIC12F635/683 , PIC16F636/684/688 , PIC16F785) * Fixed Programming PIC all PIC12F675 , PIC16F676 , PIC16F684 ,PIC16F767, PIC16F74 PIC16F872 , PIC16F876 , PIC16F877, PIC16F876A, PIC16F873A, PIC16F819 PIC16F84 , PIC16F84A , PIC16F628, PIC16F628A, eprom PIC12C509JW , PIC16C505JW , PIC16C711JW , PIC16CE625JW PIC18F458 , PIC18F4320 , PIC18LF258 , PIC18F4539 , PIC18F4431 * Fixed Write/read/verify EEPROM 18F4550 * Fixed Bug program 18Fxxx run on Windows XP/2000 (test PIC18F4539 , PIC18F2680 , PIC18F2431 , PIC18F258 , PIC18F4220 , PIC18F4550) * Add find OSCCAL 10Fx00, 12F50x, 12F6xx * (test PIC10F202, 12F509, 12F675) * Can be expanded by adding various adapters (Optional) - PIC + adapter, 16 bit 40pin/42pin Adapter, PLCC32, PLCC44 - ATMEL AT89/MCS-51, FWH/HUB adapter - TSOP48, TSOP32 Adapter and more. * Uses the power supply from a USB port or from an optional power supply or plug pack (not supplied) Note: Higher Vcc voltages (5.6v and 6.2v) will be available when an external AC power supply is used. * The back of circuit board is covered by a sheet of perspex and completely protected from a short circuit. * Willem EPROM Programmer Version. (PCB4.5C) with 32 pin ZIF socket * Software willem (included in CD) * Manual using the Program Willem EPROM (included in CD) Software Version 0.98d5 - update September 2005 Software Version 0.98d4 - update August 2005 Software Version 0.98d3 - more support for PIC micro's Software Version 0.98d2 - further support for 3.5/3.7/4c Software Version 0.98d1 - stability and support for 3.5/3.7/4c Software Version 0.98d - some fixes for XP Software Version 0.98c - adds lots of support for PIC micro's. Software Version 0.98a ( 0.98a [alpha] ) Software Version (0.98ap) *** CAN UNLOCK AM29F040B *** Other software Versions are on the CD Willem EPROM Software Operating Manual (included on the CD) * Deliverly time is approximately 2-7 days If you have any questions, please feel free to contact sivava email picture , we will try our best to resolve any problems you may have. The Willem EPROM Programmer can support CHIPS (EPROM,EEPROM,FLASH,I2C,PIC,MCS-51,AVR, 93Cxx, ISP) 27C64 , 27C128 , 27C256 , 27C512 , 27C010 , 27C020 , 27C M27C1001 , M27C2001 , M27C4001 27C080 (A19) , M27C801 , M87C257 2716(Vpp25V) , 2732 , (adapter DIP24) 2764 , 27128 , 27256 , 27512 , 27010, Vpp12.5V (21Vpp Modify Circuit) 28C65 , 28C64 , 28C128 , 28C256 , 28C512 , 28C010 , 28C020 , 28C040 (Adapter or Jumper) 28C16,XLS2816 (DIP24) 28F64 , 28F128 , 28F256 , 28F512 , 28F010 , 28F020 MX26C1000 , MX26C2000 , MX28F1000 , MX28F2000 Am28F256A , Am28F512A , Am28F010A , Am28F020A (New command erase/prog.) i28F001BX , 28F004 , 28F008 , 28F016 29F64 , 29F128 , 29F256 , 29F512 , 29F010 , 29F020 , 29F040 , 29F080 29F001 , 29F002 , 29F004 , 29F008 , 29F016 , 29F032 , V29C51002T , 29LV040 24C02 , 24C04 , 24C08 , 24C16 , 85C72 , 85C82 , 85C92 24C32 , 24C64 , 24C128 , 24C256 , 24C512 <- Data 8bit -> (pin 6 ->ORG. [Schematic connect to GND]) 93C06 , 93C46 , 93LC46 , 93C56 , 93C57, 93C66 , 93C76 , 93C86 (8bit) , AT59C11 , AT59C22 , AT59C13 CAT35C102 , CAT35C104 , CAT35C108 (pullup pin7) <-Data 16bit-> (pin 6 ->NC [No Connect]) 93C06A , 93C46X , 93C56 , 93C66 , 93C76 , 93C86 (NS) 16C84 , 16F84 ,16F84A , 16F627/16F628 12C508/A , 12C509/A , 12CE518 , 12CE519 , 16C505 16C620 , 16C621 , 16C622 , 16CE623 , 16CE624 , 16CE625 , 16C710/711 16F870 , 16F871 , 16F872 , 16F873 , 16F874 , 16F876 , 16F877 PIC16F873A , PIC16F874A , PIC16F876A , PIC16F877A PIC12F629 , PIC12F675 , PIC16F630 , PIC16F676 , PIC12F635 , PIC12F683 , PIC16F636 , PIC16F684 , PIC16F688 PIC16F72/73/74/76/77 , PIC16F737/747/767/777 , PIC16F87/88 , rfPIC12F675x , PIC16F785/PS200 , PIC16F716 -Add microchip 14bit,12bit OTP PIC12C671 , PIC12C672 , PIC12CE673 , PIC12CE674 PIC16C61/71 , PIC16C62/64/65/73 , PIC16C62A/62B/62C/63/63A/64A/65A/65B/66/67 PIC16C72/72A/73A/74A/74B/76/77 , PIC16C620/620A/621/621A/622/622A PIC16CE/623/624/625 , PIC16C710/711/712/716 , PIC16C773/774 , PIC16C745/765/923/924 , PIC16C925/926 PIC16C554/556/557/558 , PIC16C432/433 , PIC16C717/770/771/781/782 -Additional PIC microchip 14bit PIC12F629/675 , PIC16F630/676 , PIC12F635/683 , PIC16F636/684/688 , PIC16F72/73/74/76/77 , PIC16F737/747/767/777 , PIC16F87/88 , rfPIC12F675x , PIC16F785/PS200 , PIC16F716 -Additional microchip 14bit OTP PIC12C671 , PIC12C672 , PIC12CE673 , PIC12CE674 , PIC16C61/71 , PIC16C62/64/65/73 , PIC16C62A/62B/62C/63/63A/64A/65A/65B/66/67 , PIC16C72/72A/73A/74A/74B/76/77 , PIC16C620/620A/621/621A/622/622A , PIC16CE/623/624/625 , PIC16C710/711/712/716 , PIC16C773/774 , PIC16C745/765/923/924 , PIC16C925/926 , PIC16C554/556/557/558 , PIC16C432/433 , -Additional PIC microchip 12bit (FLASH memory) PIC12F508/509 , PIC10F200/202/204/206 , PIC16F505 , PIC16F54/57 PIC18F242 , 18F248 , 18F252 , 18F258 , 18F442 , 18F448 , 16F452 , 16F458 PIC18F1220 , 18F2220 , 18F4220 , 18F1320 , 18F2320 , 18F4320 PIC18F6520 , 18F6620 , 18F6720 , 18F8520 , 18F8620 , 18F8720 PIC18F2331 , 18F2431 , 18F4331 , 18F4431 PIC18F6525 , 18F6621 , 18F8525 , 18F8621 PIC18F6585 , 18F6680 , 18F8585 , 18F8680 PIC18F2439 , 18F2539 , 18F4439 , 18F4539 PIC18F6410 , 18F8410 , 18F6490 , 18F8490 PIC18F2410 , PIC18F2420 , PIC18F2455 PIC18F2510 , PIC18F2515 , PIC18F2520 , PIC18F2525 , PIC18F2550 , PIC18F2585 PIC18F2610 , PIC18F2620 , PIC18F2680 PIC18F4410, PIC18F4420 , PIC18F4455 PIC18F4510 , PIC18F4515 , PIC18F4520 , PIC18F4525 , PIC18F4550 , PIC18F4585 PIC18F4610 , PIC18F4620 , PIC18F4680 -Additional Find and edit value OSCCAL (PIC12F629/675 , PIC16F630/676) -Additional Edit config at address 0x2008,0x2009 (PIC12F635/683 , PIC16F636/684/688 , PIC16F785) PIC12F675 , PIC16F676 , PIC16F684 ,PIC16F767, PIC16F74 PIC16F872 , PIC16F876 , PIC16F877, PIC16F876A, PIC16F873A, PIC16F819 PIC16F84 , PIC16F84A , PIC16F628, PIC16F628A, eprom PIC12C509JW , PIC16C505JW , PIC16C711JW , PIC16CE625JW PIC18F458 , PIC18F4320 , PIC18LF258 , PIC18F4539 , PIC18F4431 AT29C256 , AT29C512 , AT29C010A , AT29C020 , AT29C040 , AT29C040A W29EE512 , W29EE011 , W29EE012 , W29C020(128) , W29C040 ASD AE29F1008 (AT29C010), AE29F2008 (AT29C020) Ver 0.992 up(DOS). Can run under win9x (disable prog. CPUIdle or CPUCool) Command seq. 5555/AA, 2AAA/55, 5555/A0 AT49F512 , AT49F010 , AT49F020 , AT49F040 SST39SF010 , SST3S9F020 ,SST39SF040 AT49F001 , AT49F002 , AT49F008A Command seq. 555/AA, 2AA/55, 555/A0 Am29F512 , Am29F010 , Am29F020 , Am29F040 , HY29F080 Serial Peripheral Interface (SPI) [Atmel] AT25010 , 020 , 040 (A8-A0) AT25080 , 160 , 320 , 640 , 128 , 256 (A15-A0) [ST] W95010....256, Microchip 25x010 - 25x640 25C080 , 25C160 , 25C320 , 25C640 , 25C128 , 25C256 , 25C512 AT25HP256 , AT25HP512 , M25P10 , M25P20 , M25P40 - CAT64LCxxx (16bit DATA IN/OUT) use Socket 93Cxxx CAT64LC010, CAT64LC020, CAT64LC040 AT28C256 , AT28C010 , AT28C040 DS1220 , DS1225Y , DS1230Y/AB , DS1245Y/AB , DS1249Y/AB 6116 , 6264 , 62256 , 62512 , 628128 W27E512 , W27E010 , W27C010 , W27C020 , W27C040 SST27SF256 , SST27SF512 , SST27SF010 , SST27SF020 Vcc = 3.3-3.6V SST37VF512 , SST37VF010 , SST37VF020 , SST37VF040 AT89C51 , 52 , 55 , AT89LV51 , 52 , 55 AT89S8252 (8K+2K) , AT89S53 , AT89LS8252 , AT89LS53 AT89C1051 , AT89C2051 , AT89C4051 (20pin) AT89C51RC (32KB) , AT89C55WD (6.2V) i8xC51 , i8xC52 , i8xC54 , i8xC58 (tWP = 100uS*25 Pulse) (read , write , erase , verify , checkempty , Lockbits , Fusebits) [Flash memory/EEPROM] 90S2333 , 90S4433 , 90S4414 , 90S8515 , 90S4434 , 90S8535 Function Lockbit read AT90S2313 Errata Sheet.pdf P8048AH , P8049AH,P8050AH , P8042AH Vea = 12V P8748 , P8749H , P8742H Vea = 18V D8748 , D8749 , D8742 , D8741 , D8742 Vea = 18V Am29F400 , Am29F800 , 29F160 , 29F320 (read , write byte mode) HY29F200 , HY29F400 , HY29F800 , AT49F2048A , AT49F4096A , AT49F8192A i28F200 , i28F400 , i28F800 , i28F160 (TSOP48) 27C1024 (27C210) , 27C2048 (27C2002) , 27C4096 (27C4002), by use Resister pull up Data Bus (0xFF) , A0 select low or high byte) EPROM 16bit (DIP42) (4-32Mbit) M27C400(DIP40) , 27C800 , 27C160 , 27C322 by use Resister pull up Data Bus (0xFF), A0 select low or high byte) 29LV200 , 29LV400 , 29LV800 , 29LV160 , 29LV320 (read,write byte mode) Adapter Firmware Hub/LPC (PLCC32) (PP mode) (3.3V) 82802AB , 82802AC , AT49LW040 , AT49LW080 SST49LF002A , SST49LF003A , SST49LF004A , SST49LF008A W49V002A , W39V040A , PT49V004 MBM29LV002TA/BA , MBM29LV004 , MBM29LV008 , MBM29LV017 , MBM29LV080 MBM29F002ST/SB , MBM29LV016 , Am29LV004 , Am29LV002 , Am29LV008 MBM29F017A , MBM29F016A , MBM29F080 , 28F008SA , 29F004S5 Am29F080 , Am29F016B , Am29F016 , Am29F017B , Am29F065MU Copyright © 2002-2008 sivava All rights reserved. Last Update: April 12nd 2007 (all content is the responsibility of the poster) |
